| Camera |
| Image Sensor |
1/1.8 inch CMOS |
| Min. Illumination |
Color:0.0001Lux@(F1.0,AGC ON),B/W:0Lux with IR |
| Shutter Time |
1s~1/100000s |
| Day&Night |
No IR-cut |
| WDR |
120dB |
| S/N |
>46dB |
| Angle Adjustment |
0~360°(P); 0~90°(T); 0~360°(R) |
| Lens |
| Lens Type |
Fixed focal lens |
| Focal Length |
4mm |
| Lens Mount |
M16 |
| Aperture Range |
F1.0 |
| Aperture Type |
Fixed |
| Field of View |
94.5°(H); 50.2°(V); 110.2°(D) |
| DORI Distance |
Detect: 80m
Observe: 31.7m
Recognize: 16m
Identify: 8m |
| Illuminator |
| White LEDs |
4 |
| Whitelight Distance |
15m |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
| Video Bit Rate |
32k~16Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
| Audio Sampling Rate |
8kHz/32kHz/48kHz |
| Image |
| Max. Resolution |
4MP,2688×1520@25fps |
| Main Stream |
PAL: 25fps (2688×1520, 2560×1440, 2304×1296), 50fps (1920×1080, 1280×720)
NTSC: 30fps (2688×1520, 2560×1440, 2304×1296), 60fps (1920×1080, 1280×720) |
| Sub Stream |
PAL: 25fps(704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
| Third Stream |
PAL: 25fps (1280×720, 704×576, 704×288, 352×288)
NTSC: 30fps (1280×720, 704×480, 704×240, 352×240) |
| BLC |
Yes |
| HLC |
Yes |
| AGC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
| ROI |
8 rectangular static areas |
| Corridor Mode |
Yes |
| OSD |
Overlay of additional characters in 5 regions, 2 lines, with a maximum of 127 characters or 42 Chinese characters per region; 16*16/32*32/48*48/64*64/96*96 |
| Picture Overlay |
1*200×200 size BMP 24 color bit image overlay |
| Privacy Mask |
4 black static areas |
| Defog |
Yes |
| Feature |
| General Alarm |
Motion Detection; Mask Alarm |
| Exceptions Alarm |
Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server Exception |
| Linkage Method |
Send Email; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output |
| Video Analytics |
Human/Vehicle Classification; Tripwire; Perimeter |
| Rules of Behavior Analyse In 1 Scene |
7 |
| Network |
| ANR |
Yes |
| Protocols |
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1v2v3; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1X; QoS; IPv4; IPv6; PPPoE; SSH; Unicast; Multicast; RTCP; ARP; RTP; SRTP; FTP; SFTP |
| System Compatibility |
ONVIF(Profile S/T/G/M) ; SDK; CGI; Milestone; RTSP; RTMP |
| Remote Connection |
≤7 |
| Client |
Easy7 VMS |
| Moblie Client |
EasyLive Plus |
| Web |
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
| Interface |
| Communication Interface |
1*RJ-45 (10/100 Base-T) |
| Built-in Mic |
Yes |
| Reset Button |
Yes |
| On-board Storage |
Support microSD/microSDHC/microSDXC card,up to 512GB |
| RTC |
Yes |
| General |
| Web Client Language |
19 languages
Simple Chinese/ Traditional Chinese/ English/ Spanish/ Korean/ Italian/ Turkish/ Russian/ Thai/ French/ Polish/ Dutch/ Hebrew/ Arabic/ Vietnamese/ German/ Ukrainian/ Portuguese/ Albanian |
| Operating Temperature |
-40℃~65℃(-40℉~149℉) |
| Operating Humidity |
≤95%RH |
| Storage Temperature |
-40℃~65℃(-40℉~149℉) |
| Storage Humidity |
10%~95%RH(non-condensing) |
| Power Supply |
DC12V±25%,Max. 8W; PoE:IEEE 802.3af,Max. 9W |
| Protection |
Surge4000V; ESD6000V; IP67 |
| Boundary Dimensions |
239(L) x 90(W) x 90(H) mm |
