| Camera |
| Image Sensor |
1/3” CMOS |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.02Lux@ (F1.6, AGC ON), B/W: 0Lux with IR |
| Shutter Time |
1s to 1/100,000s |
| Day & Night |
Dual IR Cut Filter with Auto Switch |
| Wide Dynamic Range |
Digital WDR |
| Angle Adjustment |
pan 0~340°, tilt 0~75°, roate 0~360° |
| Lens |
| Lens Type |
Fixed |
| Focus |
2.8mm |
| Lens Mount |
M12 |
| Aperture |
F2.0, Fixed |
| FOV |
Horizontal field of view: 92.8°(2.8mm)
Vertical field of view: 52.2°(2.8mm)
Diagonal field of view: 104.8°(2.8mm) |
| Illuminator |
| IR Range |
Up to 30m |
| Wavelength |
850nm |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264 |
| Video Bit Rate |
32Kbps~6Mbps |
| Audio Compression |
G.711/G.711U/ADPCM |
| Audio Bit Rate |
8K~48Kbps |
| Image |
| Max. Resolution |
2560×1440 |
| Main Stream |
PAL: 20fps(2560×1440,2304×1296,1920×1080,1280×720)
NTSC:20fps(2560×1440,2304×1296,1920×1080,1280×720) |
| Sub Stream |
PAL: 20fps(704×576,704×288,352×288,640×360）
NTSC: 20fps(704×480,704×240,352×240,640×360） |
| Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement |
BLC/3D DNR/HLC |
| OSD |
16×16, 32×32, 48×48, 64×64,adaptable size, Letters Such as Week, Date, Time, Total 1 Regions |
| Privacy Mask |
Yes, 4 regions |
| Feature |
| Alarm Trigger |
Motion Detection, Mask Alarm, IP Address Conflict |
| Network |
| Protocols |
HTTP,TCP/IP,UDP,ICMP,DHCP,DNS,NTP,IPv4,Telnet |
| System Compatibility |
ONVIF (PROFILE S/T), SDK, CGI |
| Remote Connection |
≤2 |
| Client |
Easy7, EasyLive Plus |
| Web Version |
Web6 |
| Interface |
| Communication Interface |
1 RJ45 10M/ 100M self adaptive Ethernet port |
| Audio I/O |
Mic in |
| General |
| Web Client Language |
12 languages
English, Arabic, Italian, Spanish, Japanese, Vietnamese, Thai, Turkish, Russian, Polish, Portuguese, French |
| Operating Conditions |
-30℃～60℃, 0～95% RH |
| Dimensions |
117mm(D)×96mm(H) |
| Weight |
0.24kg |
