| Camera |
| Image Sensor |
1/2.7 inch CMOS |
| Min. Illumination |
Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR |
| Shutter Time |
1s~1/100000s |
| Day&Night |
IR-cut filter with auto switch (ICR) |
| Smart IR |
Yes |
| WDR |
120dB |
| S/N |
>39dB |
| Lens |
| Lens Type |
Fixed focal lens |
| Focal Length |
1.4mm |
| Lens Mount |
M12 |
| Aperture Range |
F2.0 |
| Aperture Type |
Fixed |
| Field of View |
180°(H); 180°(V); 180°(D) |
| DORI Distance |
Detect: 24m
Observe: 9m
Recognize: 4.8m
Identify: 2.5m |
| Illuminator |
| IR LEDs |
3 |
| IR Distance |
Up to 30m |
| Wavelength |
850nm |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
| Video Bit Rate |
32k~16Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
| Audio Sampling Rate |
8kHz/32kHz/48kHz |
| Image |
| Max. Resolution |
5MP,2592×1944@30fps |
| Main Stream |
PAL:25fps(2592×1944, 2560×1440, 1920×1080, 1280×720)
NTSC:30fps(2592×1944, 2560×1440, 1920×1080, 1280×720) |
| Sub Stream |
PAL:25fps(704×576, 704×288, 640×360, 352×288)
NTSC:30fps(704×480, 704×240, 640×360, 352×240) |
| Third Stream |
PAL:25fps(1920×1080, 1280*720)
NTSC:30fps(1920×1080, 1280*720) |
| BLC |
Yes |
| HLC |
Yes |
| AGC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
| ROI |
8 rectangular static areas |
| OSD |
Overlay of additional characters in 5 regions, 2 lines, with a maximum of 127 characters or 42 Chinese characters per region; 16*16/32*32/48*48/64*64/96*96 |
| Picture Overlay |
1*200×200 size BMP 24 color bit image overlay |
| Privacy Mask |
4 black static areas |
| Defog |
Yes |
| Feature |
| General Alarm |
Motion Detection; Mask Alarm; Alarm Input |
| Exceptions Alarm |
Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; MAC Address Conflict; FTP Server Exception |
| Linkage Method |
Send Email; Trigger Sound; Trigger Recording; Trigger Capture; Notify Surveillance Center; Alarm Output |
| Video Analytics |
Tripwire; Perimeter; Heatmap |
| Rules of Behavior Analyse In 1 Scene |
8 |
| Network |
| ANR |
Yes |
| Protocols |
HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1v2v3; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1X; QoS; IPv4; IPv6; PPPoE; SSH; Unicast; Multicast; RTCP; ARP; SRTP; FTP; SFTP |
| System Compatibility |
ONVIF(Profile S/T/G) ; SDK; CGI; Milestone; RTSP; RTMP |
| Remote Connection |
≤2 |
| Client |
Easy7 VMS |
| Moblie Client |
EasyLive Plus |
| Web |
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
| Interface |
| Communication Interface |
1*RJ-45 (10/100 Base-T) |
| Audio I/O |
1; 1 |
| Alarm I/O |
1-ch,TTL input,3mA,3.3VDC; 1-ch,TTL output,30mA,12VDC |
| Built-in Mic |
Yes |
| Reset Button |
Yes |
| On-board Storage |
Support microSD/microSDHC/microSDXC card,up to 512GB |
| RTC |
Yes |
| General |
| Web Client Language |
17 languages
Simple Chinese/ Traditional Chinese/ English/ Spanish/ Korean/ Italian/ Turkish/ Russian/ Thai/ French/ Polish/ Dutch/ Hebrew/ Arabic/ Vietnamese/ German/ Ukrainian |
| Operating Temperature |
-40℃~65℃(-40℉~149℉) |
| Operating Humidity |
≤95%RH |
| Storage Temperature |
-40℃~65℃(-40℉~149℉) |
| Storage Humidity |
10%~95%RH(non-condensing) |
| Power Supply |
DC12V±25%,Max. 8.5W; PoE:IEEE 802.3af,Max. 9.5W |
| Protection |
Surge4000V; ESD6000V |
| Boundary Dimensions |
122(L) x 122(W) x 39(H) mm |
