| Camera |
| Image Sensor |
1/2.8 inch CMOS |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.02Lux@ (F2.0, AGC ON), B/W: 0Lux with IR |
| Shutter Time |
1s to 1/100,000s |
| Day & Night |
Dual IR Cut Filter with Auto Switch |
| Wide Dynamic Range |
Digital WDR |
| Angle Adjustment |
pan 0~340°, tilt 0~75°, roate 0~360° |
| Lens |
| Lens Type |
Fixed |
| Focus |
2.8mm |
| Lens Mount |
M12 |
| Aperture |
F2.0, Fixed |
| FOV |
Horizontal field of view: 99.7° |
| Illuminator |
| IR LEDs |
2 |
| IR Range |
Up to 30m |
| Wavelength |
850nm |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264 |
| Video Bit Rate |
32Kbps~6Mbps |
| Audio Compression |
G.711/G.711U/ADPCM |
| Audio Bit Rate |
8K~48Kbps |
| Image |
| Max. Resolution |
1920×1080 |
| Main Stream |
PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) |
| NTSC: 30fps (1920×1080,1280×720, 704×480, 640×480) |
| Sub Stream |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
| NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
| Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement |
BLC/3D DNR/HLC |
| OSD |
16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions |
| Privacy Mask |
Yes, 4 regions |
| Smart Defog |
Yes |
| Feature |
| Alarm Trigger |
Motion Detection, Mask Alarm, IP Address Conflict |
| Video Analytics |
Tripwire, Perimeter |
| Network |
| ANR |
Yes(Only Support Tiandy ANR NVR) |
| Protocols |
TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP |
| System Compatibility |
ONVIF (PROFILE S/T/G), SDK, P2P(Mutually exclusive with Profile G) |
| Remote Connection |
≤7 |
| Client |
Easy7, EasyLive |
| Web Version |
Web5 |
| Interface |
| Communication Interface |
1 RJ45 10M/ 100M self adaptive Ethernet port |
| Audio I/O |
Mic in |
| Reset Button |
Yes |
| On-board storage |
Built-in MicroSD card slot, up to 512 GB |
| General |
| Web Client Language |
15 languages
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese |
| Operating Conditions |
-40℃～65℃, 0～95% RH |
| Power Supply |
DC 12V±25%, PoE (802.3af) |
| Power Consumption |
MAX: 6W (12V) MAX: 7W (PoE) |
| Protection |
IP67, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017 |
| Dimensions |
Φ116.6×83.7mm (Φ4.59×3.30inch) |
| Weight |
Metal+Plastic: 0.3Kg (0.66lb) Metal: 0.45Kg (0.99lb) |
