| Camera |
| Image Sensor |
1/3 inch CMOS |
| Min. Illumination |
Color:0.02Lux@(F1.6,AGC ON),B/W:0Lux with IR |
| Shutter Time |
1s~1/100000s |
| Day&Night |
IR-cut filter with auto switch (ICR) |
| WDR |
DWDR |
| S/N |
>40dB |
| Angle Adjustment |
(P)Fixde Lens: -60°~60°, Pan & Tilt Lens: 0~345°;
(T)Fixde Lens: 5°-15°, Pan & Tilt Lens: -15~90°;
(R)Fixde Lens: 0°, Pan & Tilt Lens: 0° |
| Lens |
| Lens Type |
Fixed |
| Focal Length |
4mm/4mm |
| Lens Mount |
M12/M12 |
| Aperture Range |
F1.6/F1.6,fixed focal lens |
| Field of View |
(H)Fixde Lens:81.3°; Pan & Tilt Lens:81.3°
(V)Fixde Lens:44.4°; Pan & Tilt Lens:44.4°
(D)Fixde Lens:94.4°; Pan & Tilt Lens:94.4° |
| DORI Distance |
Fixde Lens: Detect: 59.26m; Observe: 23.52m; Recognize: 11.85m; Identify: 5.93m
Pan & Tilt Lens: Detect: 59.26m; Observe: 23.52m; Recognize: 11.85m; Identify: 5.93m |
| Illuminator |
| IR LEDs |
4+4 |
| IR Distance |
50m |
| Wavelength |
850nm |
| White LEDs |
4+4 |
| Whitelight Distance |
15m |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264B/H.264M/H.264H |
| Video Bit Rate |
Fixde Lens: 32k~4Mbps
Pan & Tilt Lens: 32k~4Mbps |
| Audio Compression |
G.711A/G.711U |
| Audio Sampling Rate |
8kHz/16kHz |
| Image |
| Max. Resolution |
2304×1296@15fps |
| Main Stream |
Fixde Lens
PAL: 15fps(2304×1296, 1920×1080, 1280×720, 640×480, 704×576)
NTSC: 15fps(2304×1296, 1920×1080, 1280×720, 640×480, 704×480)
Pan & Tilt Lens:
PAL: 15fps(2304×1296, 1920×1080, 1280×720, 640×480, 704×576)
NTSC: 15fps(2304×1296, 1920×1080, 1280×720, 640×480, 704×480) |
| Sub Stream |
Fixde Lens:
PAL: 15fps(704×576, 704×288, 640×360, 352×288)
NTSC: 15fps(704×480, 704×240, 640×360, 352×240)
Pan & Tilt Lens:
PAL: 15fps(704×576, 704×288, 640×360, 352×288)
NTSC: 15fps(704×480, 704×240, 640×360, 352×240) |
| BLC |
Yes |
| HLC |
Yes |
| AGC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance |
| OSD |
Overlay of additional characters in one area, 1 line, up to 48 characters or 16 Chinese characters;16*16/32*32/48*48 |
| Privacy Mask |
4 black static areas |
| Defog |
Yes |
| Feature |
| Alarm Trigger |
Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict |
| Auto-Tracking |
Auto-Tracking |
| Linkage Method |
trigger sound; trigger recording; trigger capture; notify surveillance center |
| Network |
| ANR |
Yes |
| Protocols |
HTTP; TCP/IP; UDP; ICMP; DHCP; DNS; NTP; IPv4; SSH; Unicast; FTP |
| System Compatibility |
P2P;CGI |
| Remote Connection |
≤2 |
| Client |
Easy7 Smart Client |
| Moblie Client |
EasyLive Lite |
| Web |
IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+ |
| Interface |
| Communication Interface |
1xRJ-45, 10/100 Mbps self-adaptive Ethernet port |
| Built-In Speaker |
Yes |
| Reset Button |
Yes |
| On-board storage |
Support microSD/microSDHC/microSDXC card, up to 512 GB |
| General |
| Web Client Language |
3languages
Simple Chinese/English/Vietnamese |
| Operating Temperature |
-30℃~60℃ |
| Operating Humidity |
Humidity 95% or less (no condensation) |
| Storage Temperature |
-30℃~60℃ |
| Storage Humidity |
Humidity 95% or less (no condensation) |
| Power Supply |
DC12V±25% |
| Protection |
Surge2000V; ESD6000V; IP66 |
| Boundary Dimensions |
133(L) x 102(W) x 209(H) mm |
| Net Weight |
0.6kg |
