Thông số kỹ thuật
| Outline |
| Mixing capability |
On-board processors |
SPX algorithm: 6 programs |
| I/O |
Phantom power |
+48 V |
| Digital I/O |
– |
| Input Channels |
Mono[MIC/LINE] |
2 |
| Mono/Stereo[MIC/LINE] |
– |
| Stereo[LINE] |
2 |
| Output Channels |
STEREO OUT |
2 |
| MONITOR OUT |
– |
| PHONES |
1 |
| AUX SEND |
– |
| GROUP OUT |
– |
| Bus |
Stereo: 1 |
| Input Channel Function |
PAD |
26 dB (Mono) |
| HPF |
80 Hz, 12 dB/oct (Mono) |
| COMP |
– |
| EQ HIGH |
(Mono) Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving |
| EQ MID |
– |
| EQ LOW |
(Mono) Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving |
| PEAK LED |
LED turns on when post EQ signal reaches 3 dB below clipping |
| Level Meter |
2 x 7 -segment LED meter [PEAK, +6, +3, 0, -3, -10, -20 dB] |
| General specifications |
| Total harmonic distortion |
0.01 % @ +8dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +18dBu (1kHz), GAIN knob: Min |
| Frequency response |
+0.5 dB/-0.5 dB (20 Hz to 20 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min |
| Hum & noise level |
Equivalent input noise |
-128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max) |
| Residual output noise |
-102 dBu (STEREO OUT, STEREO LEVEL knob: Min) |
| Crosstalk |
-88 dB |
| Power requirements |
PA-130 (DC12 V/1.0 A, Cable length = 1.8 m), 120 V, 60 Hz, MU18 (DC12 V/1.5 A, Cable length = 1.5 m), 100 V-240 V, 50 Hz/60 Hz or equivalent recommended by Yamaha |
| Power consumption |
12 W |
| Dimensions |
W |
149 mm (5.9″) |
| H |
62 mm (2.4″) |
| D |
202 mm (7.9″) |
| Net weight |
0.9 kg (1.98 lbs.) |
| Accessories |
Included Accessory: AC Adaptor, Owner’s Manual, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A |
| Others |
Operating Temperature: 0 to +40˚C |
